ABB 3BSE040364R1 TU834 module card

ABB 3BSE040364R1 TU834  module card

Technical data of product parameters

The ABB 3BSE040364R1 TU834 module card is a communication interface module designed for use in ABB’s System 800xA Distributed Control System. The module provides a high-speed communication interface between the system controller and field devices, allowing for efficient and reliable control of industrial processes. Here are some details about the ABB 3BSE040364R1 TU834 module card:

1. Communication protocol: The TU834 module card supports the HART communication protocol, which is widely used in the process industry for transmitting information between field devices and control systems.
2. Number of channels: The module card has 8 channels, each capable of handling multiple field devices.
3. Communication speed: The module card has a communication speed of up to 115.2 kbit/s, allowing for fast and reliable data transmission.
4. Signal types: The module card supports both analog and digital signals, allowing for flexible communication with a wide range of field devices.
5. Redundancy: The module card features a redundant communication bus for increased reliability and availability.
6. Power supply: The module card requires a 24V DC power supply, with a maximum power consumption of 10W.
7. Temperature range: The module card is designed to operate in a temperature range of -40°C to +70°C (-40°F to +158°F), making it suitable for use in harsh industrial environments.
8. Certifications: The module card is CE certified and meets international standards for safety and environmental compliance.
9. Size: The module card measures 150mm x 72mm x 114mm (5.9in x 2.8in x 4.5in), making it a compact and space-efficient solution for communication interface applications.

Overall, the ABB 3BSE040364R1 TU834 module card is a reliable and efficient solution for communication between field devices and control systems in industrial processes. Its support for the HART communication protocol, multiple channels, high communication speed, support for analog and digital signals, redundancy, power supply requirements, temperature range, certifications, and compact size make it an ideal module for a wide range of industrial applications.

Product picture display
