ABB 3BDH000364R0002 PM783FB0 drive sensor

ABB 3BDH000364R0002 PM783FB0 drive sensor

Technical data of product parameters

A wire jumper between terminals IAO and logic GND can be used to set the analog
output to Inverse Operation.
Normal (default – no wire installed) operation of the analog output means that when
the output value is 0% (as seen at the SLIM or Controller), the analog output is a 3BDH000364R0002 PM783FB0
minimum (0V for groups 1 and 2, or 4mA for groups 3 and 4 modules.) When the
output value is 100%, the actual analog output is at its maximum value (+10V for
group 1, +5V for group 2, and 20mA for groups 3 and 4 modules).
Inverse (wire jumper installed) operation of the analog output means that when the
output value is 0% (as seen at the SLIM or Controller), the analog output is a
maximum (+10V for group 1, +5V for group 2, and 20mA for groups 3 and 4
modules). When the output value is 100%, the analog output is its minimum value 3BDH000364R0002 PM783FB0
(0V for groups 1 and 2, or 4mA for groups 3 and 4 modules).
If the Loop Interface subsystem uses the 1C31177G02 Personality module
(configured for two 4 to 20 mA current analog inputs that are locally powered),
the required voltage supply may be obtained from the internal auxiliary power
supply (backplane), or it may be obtained from an external power supply.
If an external voltage power supply is used, see Appendix D for the steps to be
undertaken before connecting the external power supply to the Loop Interface
module base unit terminal block. The Loop Interface module auxiliary supply
voltage level (24 VDC or 48 V DC) depends on the external transmitter devices 3BDH000364R0002 PM783FB0
being interfaced to the Loop Interface module’s analog inputs.If desired, the digital input auxiliary supply voltage may be the same voltage as that used for the digital outputs. This voltage is
provided as an output between terminals Vf+ and V-. This fused
voltage (Vf+) is monitored as an additional digital input. Input
characteristics are identical to the other two digital inputs.The return line and auxiliary power supply voltage is
common to both points but is galvanically isolated from
logic ground. This auxiliary supply voltage originates
from the terminal block (on inputs V+ and V-) and is
fused on the personality module.
The fused voltage is distributed back out to the terminal
blocks as +1, +2 for the digital outputs and Vf+ for the
digital inputs. Each digital output is diode clamped to this
fused auxiliary supply voltage to prevent damage from
inductive load surges.

Product picture display
