ABB 3HAA3563-ALA module
Technical data of product parameters
The SSI interface (synchronous serial absolute-encoder emulation) is part of the package
supplied. Select encoder function3HAA3563-ALA (“Encoder” screen page).
The servo amplifier calculates the motor shaft position from the cyclic-absolute signals of
the resolver or encoder. From this information a SSI date (after Stegmann patent specification3HAA3563-ALA is provided.
28 bits are transferred. The 12 leading data bits contains the number of revolutions. The
following max. 16 bits contain the resolution and are not variable.
The following table shows the allocation of the SSI date:
Revolution Resolution
The signal sequence can be output in Gray code or in Binary (standard) code (parameter
SSI-CODE). The servo amplifier can be adjusted to the clock frequency of your SSI-evaluation through the 3HAA3563-ALAparameter (cycle time 1.3 µs or 10 µs).
The ground reference for the interface (supplied by an internal voltage) is PGND. PGND
must always be connected to the control ground.
Connection and signals for the SSI interface :
The count direction is UP when the motor shaft is rotating clockwise (looking at the end of
the motor shaft).
Product picture display
Company advantages
Warranty: Seven day acceptance period, one year warranty period
Delivery period: 1-3 working days
Advantages: supply of imported genuine products, professional off production accessories, fast delivery and accurate delivery
Main products: Focus on DCS, PLC, robot control system and large servo system. Main products: various modules/cards, controllers, touch screens, servo drives.
Main brands:
ABB Bailey, GE/FANC, FOXBORO, Invensys TRICONEX, Bentley BENTLY, A-B Rockwell, Emerson, OVATION, MOTOROLA, XYVOM, Honeywell HONEYWELL, Rexroth, KUKA, NI, DEIF, Yokogawa, Woodward WOODWARD, Ryan, Schneider SCHNEIDER, Yaskawa, Moog, PROSOFT, etc
