ABB 5SXE03-0141 3BHB003149P104 module
Technical data of product parameters
When full calibration is requested, the valve travels from its present position to 5SXE03-0141 3BHB003149P104
100%. Feedback gain is adjusted until voltage is between 9.9 volts and 10.0
volts. Each time gain is adjusted, a corresponding adjustment is made to the 0%
position calibration value. If the new gain value would cause the 0% position
voltage to exceed -10.0 Volts, the 100% calibration step is completed.
The Servo Driver is then commanded to travel to 0% position. Feedback gain is 5SXE03-0141 3BHB003149P104
adjusted until the position voltage for 0% is more positive than -10.0. For each
adjustment of gain, the 100% calibration value is adjusted accordingly. Once the
position voltage is in range, or the gain change causes the 100% value to exceed
10.0 volts, the sequence is complete.
When the full calibration sequence is completed, the new values are written to 5SXE03-0141 3BHB003149P104
EEPROM memory, and the Servo Driver executes a soft reset. The Controller
can then control the Servo Driver in normal mode after the tracking requirement
is completed.
After a major mechanical overhaul, both calibration values are invalid. Since
both calibration values limit feedback gain adjustment, the process may need to 5SXE03-0141 3BHB003149P104
be repeated to get proper feedback gain adjustment.
After a full calibration sequence, the 0% and 100% readings give a good
indication of the matching of the electrical NULL point with the midpoint of the
mechanical stroke, and the Servo Driver should be inspected by a
knowledgeable user.If the mechanical stroke remains the same after the overhaul, and the same
LVDT is installed, simply adjust the LVDT so the position feedback on the
Ovation system indicates 0% (with the valve fully closed), then tighten down
the LVDT assembly (that is, return to its former position).
