ABB DSCS150 57520001-FY receiver detection channel controller

ABB DSCS150 57520001-FY receiver detection channel controller

Technical data of product parameters

In addition to the four module LEDs, DO840 has one LED (Yellow/Red) per
channel (16) that indicate output state and channel error (Yellow = output is
energized, Off = output is de-energized, Red = channel error).
External channel error is reported if process power is low and channel has over load.
Internal channel error is reported if output driver or main power switch has failed. DSCS150 57520001-FY
Module error is reported if internal power has failed or if internal communication
link between the modules in redundant applications has failed.
The outputs can be set in two different modes for handling of over load, automatic
reset or latch on fault mode.
The outputs are current limited and protected against over temperature. If the DSCS150 57520001-FY
outputs are overloaded the output current will be limited. In automatic reset mode
the power dissipation in the output stage will increase and the output will shutdown
if the temperature in the output stage increases above 150°C (302° F). The output
will switch on again automatically as the component temperature has decreased to
about 140°C (284° F). In Latch on Fault mode the outputs will switch off and stay DSCS150 57520001-FY
so until the overload has disappeared and the fault is acknowledged. If any output is
shutdown due to overload the indication LED on that channel is also switched to
red. Five different types of MTUs can be used for single applications. TU830/TU833
Extended MTU and TU810 (or TU814). The TU812 Compact MTU has a D-Sub 25
pin (male) connector for connection to the process.
For redundant applications there are three types of MTUs, TU842/TU852 for
mounting on a horizontal DIN rail and TU843 for mounting on a vertical DIN rail.

Product picture display
