ABB DSRF197 3BSE019297R1 Module Description

ABB DSRF197 3BSE019297R1 Module Description

Technical data of product parameters

The ABB DSRF197 3BSE019297R1 is a spare part module for ABB’s System 800xA distributed control system (DCS). This module is a signal converter, designed to convert input signals from thermocouples or resistance temperature detectors (RTDs) into a standardized output signal for further processing by the control system.

The module is housed in a compact, DIN-rail mountable enclosure and is designed to be easily installed and integrated into an existing 800xA system. It features 8 universal input channels, which can be configured for either thermocouple or RTD input signals, and provides a 4-20mA standardized output signal for each channel.

The DSRF197 module includes advanced signal processing algorithms, which provide accurate and stable output signals even in harsh industrial environments. It is designed to operate in temperatures ranging from -40°C to +85°C, and is built to withstand shock and vibration, ensuring reliable operation in industrial settings.

The module also features a range of diagnostic and calibration functions, which allow operators to monitor and adjust the performance of the module to ensure accurate and reliable operation over time.

Overall, the ABB DSRF197 3BSE019297R1 module is a critical component of ABB’s System 800xA DCS, providing reliable and accurate signal conversion for thermocouple and RTD input signals. As a spare part, it can be used to replace a faulty or damaged module to ensure minimal downtime and maximum uptime in industrial settings.

Product picture display
