ABB DTDX991A 61430001-UW spare parts

ABB DTDX991A 61430001-UW spare parts

Technical data of product parameters

The gateway interfaces to the system through a DTDX991A 61430001-UWconnection with the
communications interface module (T8151) using 100baseT Ethernet. A
second Ethernet port and serial port are provided for connection to client
networks. The gateway features a full Microsoft Windows XP license,
includes a 12 GB hard disk, and connections for a keyboard, mouse and
monitor. The configuration of communications and loading of applications
is done using locally connected peripherals or the remote desktop feature of
another networked device running Windows XP. DTDX991A 61430001-UW
The gateway is similar in size to other communication and I/O modules. It
occupies a single slot of any controller/expander chassis. The module
sources redundant power from the bus like all other modules. All user
connections are made at the rear of the module using the communications
interface adaptorThere are input channel status LEDs on the module front panel, one for each DTDX991A 61430001-UW
field input. The input status LED mode is dependent upon the voltage level
of the field I/O signal. Each field input voltage is measured and compared to
six threshold levels (four configurable and two fixed) which produce seven
threshold bands, as described in Section 8. Each threshold band can be
defined to have a particular indicator mode: off, green, red, flashing green,
or flashing red.
The configurable voltage thresholds and LED modes allow users to
customize the input measurement and status indications to suit individual
application requirements. Without customization, the default indicator
modes are suitable for digital inputs without line monitoring and arehe TMR 24V dc digital output module, shown in Figure 6-11, interfaces to
40 field devices. The module tests for stuck on and stuck off failures.
DTDX991A 61430001-UW24Vdc Digital
Output Module
The module provides automatic line-monitoring of field devices. This feature
enables the module to detect both open and short circuit failures in field
wiring and load devices.
The module utilizes automatic over-current protection (per channel). No
fuses are required.
The module provides on-board sequence of events (SOE) reporting with a
resolution of 1ms. An output change of state triggers an SOE entry. Output
states are automatically determined by voltage and current measurements on
board the module.

Product picture display
