Technical data of product parameters

The 5 VDC system voltage for the I/O subracks is taken from the flat pin plugs of the distributors XG .2 and XG .3 on the rear side of the central rack DT602 GJR2911200R1in star shape.
The power is connected to the I/O subracks on the accordingly marked flat pin plugs XG .4 for
+5 VDC and XG .12 for GND on the rear side of the I/O subracks.
The power is internally distributed to the I/O modules via the bus board.
If the power requirements of the 5 V circuits is > 18 A an additional power supply has to be DT602 GJR2911200R1
used. For this purpose the B 9361 assembly kit can be used which provides the possibility of
applying three power supplies F 7126 together with the monitoring module F 7131 in an additional subrack.
The 5 V output circuits of the additional power supply must not be switched in parallel with the
ones from the central rack. Apart from them they supply their own circuits. The reference poles
GND have to be connected together.
The power supply units of the additional power supply (assembly kit B 9361) emit monitoring DT602 GJR2911200R1
signals. These signals can be taken from the XG .1 terminal block on the rear side of the subrack (see B 9361 assembly kit). They can be fed into the PLC via digital input modules. In the
logic of the PLC the signals are used to trigger an error message.With the I/O subrack, the connection element for the I/O bus is the F 7553 coupling module
plugged into slot 17. The connection of the I/O bus between the individual I/O module subracks
is established at the rear side via the BV 7032 data cable which is connected to the plugs
XD .1 and XD .2. The I/O bus in the I/O module subracks is integrated in the bus board.
An F 7546 bus termination module is plugged into the XD .2 connector of the last I/O module
subrack to terminate the I/O bus.
