Abb rectifier 3HAA3563-AUA power transmission and distribution DSQC 249B

Abb rectifier 3HAA3563-AUA power transmission and distribution DSQC 249B

Technical data of product parameters

There is a danger of serious personal injury or death by electrical shock
or electrical arcing. Capacitors can still have dangerous voltages present
up to 5 minutes after switching off the supply power. Control and power
connections can still be live, even if the motor is not rotating.
Only install and wire the equipment when it is not live.
Make sure that the cabinet is safely disconnected 3HAA3563-AUAlock-out and warning signs).
Never remove electrical connections to the drive while it is live.
Wait at least 5 minutes after disconnecting the drive from the 3HAA3563-AUA power before touching potentially live sections of the equipment (e.g. contacts) or undoing any connections.
To be sure, measure the voltage in the DC bus link and wait 3HAA3563-AUA
fallen below 50 V.
Wrong mains voltage, unsuitable motor or wrong wiring will damage the amplifier.
Check the combination of servo amplifier and motor. Compare the rated voltage and
current of the units. Implement the wiring according to the connection diagram on p. 43.
Make sure that the maximum permissible rated voltage at the terminals L1, L2, L3 or
+DC, –DC is not exceeded by more than 10% even in the most unfavorable
circumstances (see IEC 60204-1).
Excessively high external fusing will endanger cables and devices. The fusing of the AC
supply input and 24V supply must be installed by the user, best values are given on p.26.
Hints for use of Residual-current circuit breakers (FI) p.35.
The servo amplifier’s status must be monitored by the PLC to acknowledge critical
situations. Wire the BTB/RTO contact in series into the emergency stop circuit of the
installation. The emergency stop circuit must operate the supply contactor.

Product picture display

Company advantages

Warranty: Seven day acceptance period, one year warranty period

Delivery period: 1-3 working days

Advantages: supply of imported genuine products, professional off production accessories, fast delivery and accurate delivery

Main products: Focus on DCS, PLC, robot control system and large servo system. Main products: various modules/cards, controllers, touch screens, servo drives.

Main brands:

ABB Bailey, GE/FANC, FOXBORO, Invensys TRICONEX, Bentley BENTLY, A-B Rockwell, Emerson, OVATION, MOTOROLA, XYVOM, Honeywell HONEYWELL, Rexroth, KUKA, NI, DEIF, Yokogawa, Woodward WOODWARD, Ryan, Schneider SCHNEIDER, Yaskawa, Moog, PROSOFT, etc
