ABB SACE750090R0002 REF542 plus industrial control spare parts supply card module
Technical data of product parameters
In addition to the four module LEDs, DO815 has two LEDs (one Yellow and one SACE750090R0002 REF542
Red) per channel. The Yellow LED indicates the output state (Yellow = output is
energized, Off = output is de-energized). The Red LED indicates channel errors
such as short circuit, over load, under voltage and open load (Red = channel error,
Off = no channel error).
The driver outputs provide a “free-wheel diode” to demagnetize inductive loads.
No external demagnetization arrangement is required up to loads of 1J.
DO815 outputs are able to drive filament lamp loads up to 10W, but only in SACE750090R0002 REF542
Automatic reset mode.
DO815 provides two protection operation modes. Each channel can be configured
to operate in one of the two modes:
1. Automatic reset mode (Default mode): The fault condition disappears, then the
fault disappears, and the operation is resumed.
2. Fault latching mode (This mode in not applicable in all controllers): The output
is switched off by any of the fault conditions. The fault latch remains in fault SACE750090R0002 REF542
condition until reset by temporarily setting the automatic reset mode.
The output drivers are current limited and protected against over load. If an output
has a short circuit to ground, the output current will be limited and the driver will
shutdown in order to minimize the power dissipation. In the automatic reset mode,
the output will switch on again automatically after a defined time interval. If the
short circuit condition is still present, the output is turned off again, otherwise the
normal operation is resumed.
In the fault latching mode, the output remains off until the fault condition is not SACE750090R0002 REF542
valid and the reset of the fault latch is activated. If any output is shutdown due to
fault condition, the indication LED (Yellow) on that channel remains on if the
channel is activated.The output status of the channel can be read from the module.
