ABB SR511 3BSE000863R1 voltage stabilizer

ABB SR511 3BSE000863R1 voltage stabilizer

Technical data of product parameters

Many PC communications ports connect the communications common to chassis ground. When SR511 3BSE000863R1
such a PC is connected to the controller, this can provide a path to ground for current from the
process that can enter the controller through a sensor (such as a thermocouple). This creates a
ground loop that can affect communications and other controller functions. To eliminate a ground
loop, either use an optically isolated communications adapter or take measures to ensure that SR511 3BSE000863R1
sensors and all other connections to the controller are isolated and not conducting current into
the unit.This section describes how to properly connect thermocouples, RTDs, current and voltage inputs to
your controller. The controller can accept any mix of available input types. Some input types require
that special scaling resistors be installed (done by Watlow before the controller is delivered).
All inputs are connected to the terminals on TB1 on the back of the controller. The tables below list SR511 3BSE000863R1
the connector locations.The CLS200 can accept a pulse input of up to 2000Hz from a device such as an encoder. The
frequency of this input is scaled with user-set parameters. See Setup Loop Input Menu on page
74 and Example 3: A Pulse Encoder on page 161. This scaled value is the process variable for
loop 5 on a four-loop model, loop 9 on an eight-loop model or loop 17 on a sixteen-loop model.
The CLS200 can accommodate encoder signals up to 24VDC using a voltage divider or can
power encoders with the 5VDC from the TB50 or TB18. The following figures illustrate connecting
encoders. A pull-up resistor in the CLS200 allows open collector inputs to be used.
