ABB YB161102-AE/7 rectifier robot system
Technical data of product parameters
Strip all wires and fit wire end ferrules.
Use cable ties to attach the cable to the side
or bottom shroud of the servo amplifier,
securing the braided shield of the cable to the
shroud of the servo amplifier with a cable tie.
Alternatively you can use shield connection
terminal clamps (see accessories manual).
These hook into the bottom shroud and ensure optimum contact between the shield andthe shroud.
Wire the plug-in terminal blocks as shown in
the connection diagram.The motor cable shield is connected via thebottom motor connector X9 (see below).
Strip the external cable sheath to a length of
approx. 120 mm, taking care not to damage the braided shield. Push the braided
shield YB161102-AE/7 back over the cable and secure
with a rubber sleeve (2) or shrink sleeve.
Shorten all the wires apart from the protective earth (PE) wire (green/yellow) by about
20 mm so that theYB161102-AE/7 wire is now the longest wire. Strip all wires and fit wire end ferrules.
Secure the braided shield of the cable to the
shroud with a cable tie (3) and use a second
tieYB161102-AE/7 to fasten the cable.
Wire the connector as shown in the connection diagram. Plug in the connector to the
socket on the front of the S700.
Screw the connector in place. This ensures that there is conductive contact over a
large surface area between the braided
shield and the front panel.
