ACQUISITIONLOGIC AL81G Data Acquisition Card

Add your review
Status: In Stock
  1. Analog Input Channels:
  • Number of channels: 8
  • Input type: Single-ended or differential
  • Input range: ±10 V, ±5 V, ±2.5 V, ±1.25 V, 0-10 V, 0-5 V, 0-2.5 V, 0-1.25 V, 4-20 mA, 0-20 mA
  • Resolution: 16 bits
  • Sample rate: up to 1 MS/s per channel
  1. Analog Output Channels:
  • Number of channels: 2
  • Output type: Single-ended
  • Output range: ±10 V, ±5 V, ±2.5 V, ±1.25 V, 0-10 V, 0-5 V, 0-2.5 V, 0-1.25 V
  • Resolution: 12 bits
  • Update rate: up to 1 MS/s per channel
  1. Digital Input Channels:
  • Number of channels: 8
  • Input type: TTL, CMOS, or 24 VDC
  • Input voltage range: 0-5 V, 0-3.3 V, 0-24 VDC
  • Input impedance: 10 kΩ
  1. Digital Output Channels:
  • Number of channels: 8
  • Output type: TTL or CMOS
  • Output voltage range: 0-5 V or 0-3.3 V
  • Maximum output current: 24 mA per channel
  1. PCI Express Interface:
  • Bus type: PCIe 2.0 x1 or x4
  • Data transfer rate: up to 500 MB/s
  1. Software:
  • Drivers: Windows and Linux
  • Programming libraries: C++, LabVIEW, MATLAB
  • Software tools: AcquisitionLogic Data Acquisition Software, Waveform Viewer, Signal Generator, and Datalogger

Categories:
Tags:, , ,

ACQUISITIONLOGIC AL81G Data Acquisition Card

Product Details Introduction

The AcquisitionLogic AL81G data acquisition card is a high-performance, multi-channel data acquisition card that is designed for use in a variety of applications, including industrial automation, test and measurement, and scientific research.

The AL81G card features eight analog input channels with 16-bit resolution, providing high-accuracy measurements of voltage or current signals. The card also includes two analog output channels with 12-bit resolution, which can be used for controlling external devices or generating waveforms.

In addition to the analog channels, the AL81G card features eight digital input channels and eight digital output channels, which can be used for interfacing with digital sensors and actuators.

The card connects to the host computer via a PCI Express (PCIe) interface, providing high-speed data transfer and low-latency communication. The PCIe interface also allows for the use of multiple cards in a single system, enabling the acquisition of large amounts of data from multiple sources.

The AL81G card is supported by a range of software tools, including drivers for Windows and Linux operating systems, as well as programming libraries for various programming languages, such as C++, LabVIEW, and MATLAB. The software tools provide a user-friendly interface for configuring the card, acquiring and processing data, and controlling external devices.

Overall, the AcquisitionLogic AL81G data acquisition card is a versatile and high-performance solution for acquiring and processing data in a variety of applications. Its multi-channel analog and digital inputs and outputs, along with its high-accuracy measurements and fast data transfer rates, make it a popular choice for a wide range of industries and research fields.

Product picture display

ACQUISITIONLOGIC AL81G Data Acquisition Card
