DSQ312 ABB 3HAB2214-1 module

DSQ312 ABB 3HAB2214-1 module

Technical data of product parameters

This section describes the SERCOS interface of the SERVOSTAR 400. Information on
the range of functions and the software protocol can be found in the manual “IDN Reference Guide SERCOS”.
For the fiber optic cable connection, only use SERCOS components to the SERCOS
StandardDSQ312 ABB 3HAB2214-1ight emitting diodes
s whether SERCOS telegrams are being correctly received. In DSQ312 ABB 3HAB2214-1 Phase 4 this LED should flicker, since cyclical telegrams are
being received.
ates that SERCOS telegrams are being transmitted. In the final Communication Phase 4 this LED should flicker, since cyclical telegrams are being transmitted. Check the stations addresses for the controls and the servo amplifier if:
– the LED never lights up in SERCOS Phase 1 or
– the axis cannot be operated, although the RT LED is lighting DSQ312 ABB 3HAB2214-1SERCOS communication is faulty or suffering from interference.
If this LED is very bright, then communication is suffering strong interference, or
is non-existent. Check the SERCOS transmission speed for the controls and the
servo amplifier (BAUDRATE) and the fibre-optic connection.
If this LED flickers, this indicates a low level of interference for SERCOS communication, or the optical transmitting power is not correctly adjusted to suit the
length of cable. Check the transmitting power of the (physically) previous SERCOS station. The transmitting power of the servo amplifier can be adjusted in
the setup software DRIVE.EXE on the SERCOS screen page, by altering the
parameter for the cable length.e.
