DSQC322 DCS industrial control module spare parts

DSQC322 DCS industrial control module spare parts

Technical data of product parameters

One challenge when using encoders is that they are incremental
rather than absolute devices. When using an absolute device (such
as a resolver) to determine the motor shaft position within the
rotation, the transmitted code is unambiguous. In other words, at
power-up, the system knows the position of the motor shaft.
Incremental encoders only detects how far the motor shaft has
moved from its original position. This presents a problem with
three-phase brushless motors in terms of commutation alignment.DSQC322 DCis extremely important to establish the appropriate
commutation angle within the controller. (Commutation refers to theDSQC322 DC of the electromagnetic field armature winding to the
permanent magnet fields to create optimal torque.)
For this reason, encoders or motors are often provided with
additional channels sometimes called “commutation tracks” or “Hall
emulation tracks” which provide 1-part-in-6 absolute position
information as shown in the following figure.The hall channels can be synthesized in the encoder or can be
discrete devices integrated in the motor windings. Commutation
tracks (hall channels) provide three digital channels that representDSQC322 DCo the A-phase, B-phase, and C-phase back EMF of the
motor. An encoder with Hall channels must have the correct output
for the given pole count of the motor as the Hall signals are
referencing the motor’s BEMF waveform.
