DSTC404 system spare parts card module

DSTC404 system spare parts card module

Technical data of product parameters

During braking with the aid of the motor, energy is fed back to the servo amplifier. This
energy is converted into heat in the brake resistor. The brake resistor is switched in and
out by the brake circuit. The switching thresholds for the brake circuit are adjusted to suit
the supply voltage with the aid of the setup software.
Our customer support can help you with the calculation of the brake power which is
required. A DSTC40 is described in the “Product Wiki” which is accessible at
www.wiki-kollmorgen.eu. A description of the interface can be found on page 52.
Functional description
The brake circuit starts to respond when the DC Bus link voltage reaches the set value.
If the energy which is fed back from the motor, as an average over time or as a peak
value, is higher than the preset brake power, then the servo amplifier will output the status brake power exceeded and the circuit will be switched off.
At the next internal check of the DC Bus link voltage (after a few milliseconds) an
overvoltage will be detected and the servo amplifier will be switched off, with the error
message overvoltage ( p.96).
The BTB/RTO contact DSTC40 will be opened simultaneouslyThe servo amplifiers use an integrated circuit to detect if one or more input phases
(power supply feed) fail. The behavior of the servo amplifier is set using the setup software: Under “Response to Loss of Input Phase” DSTC40) on the Basic Setup screen,
select:
Warning if the higher-level control system is to bring the drive to a standstill: Warning n05 is output if an input phase is missing, and the motor current is limited

Product picture display

Company advantages

Warranty: Seven day acceptance period, one year warranty period

Delivery period: 1-3 working days

Advantages: supply of imported genuine products, professional off production accessories, fast delivery and accurate delivery

Main products: Focus on DCS, PLC, robot control system and large servo system. Main products: various modules/cards, controllers, touch screens, servo drives.
