Technical data of product parameters

The FCM2Fs are mounted on any baseplate which
accepts both FCMs and FBMs. For F3DIO8801 982200425 the Expanded
Fieldbuses, FCM2Fs must be installed redundant,
one on each end of one of the “A” and “B” cables of
the Expanded Fieldbuses (four FCM2Fs total).
The FCM2Fs can extend any of the Expanded
Fieldbuses between the FEM100 baseplate and the
FBM baseplates. The redundant FCM2F pair on the
baseplate-side of the fiber optic extension may be
installed on the first FBM baseplate in the chain, or
on a separate baseplate, such as an FCM/FBM 2-
position baseplate. Keeping the FCM2F pair on a
separate baseplate allows the baseplate chain to use F3DIO8801 982200425
all 32 possible slots for FBMs, while including the
FCM2F pair on the first baseplate in the chain leaves
30 slots for FBMs. Figure 4 illustrates this
configuration for the first Expanded Fieldbus.Invensys, Foxboro, I/A Series, Iand the Invensys logo are
trademarks of Invensys plc, its subsidiaries, and affiliates.
All other brands and product names may be the
trademarks of their respective owners.
Copyright 2005-2011 Invensys Systems, Inc. All rights
reserved. Unauthorized duplication or distribution is strictly
prohibitedThe FEM100 modules mount on either the Two-Slot
or Four-Slot Expansion Baseplate. These baseplates
are DIN rail mounted and vertically oriented only.
These baseplates include signal connectors for the
FEM100s, redundant independent dc power
connections, and four cable connections to the F3DIO8801 982200425
2 Mbps HDLC Expanded Fieldbuses.
The Two-Slot Expansion Baseplate includes a
redundant I/O cable connection to the FCP270s.
One connector supports both A and B buses, while
the other is terminated. Alternatively, both connectors
can be used in conjunction with a Fieldbus
Splitter/Terminator (P0926KW).
The Four-Slot Expansion Baseplate includes two
slots for mounting a fault-tolerant pair of FCP270s
and their fiber optic splitter/combiners.
For more information on these baseplates, refer to
DIN Rail Mounted Modular Baseplates
