GE DS200DSFBG1ACB input and output module

GE DS200DSFBG1ACB input and output module

Technical data of product parameters

The GE DS200DSFBG1ACB is an input/output (I/O) module used in industrial control systems to interface with various field devices. Here are some details about this module:

1. Type: It is an I/O module that provides interface signals to and from field devices.
2. Compatibility: It is compatible with GE’s Mark IV and Mark V control systems.
3. Communication Protocol: The module communicates with the control system using the Genius communication protocol.
4. I/O Channels: The module has 16 input channels and 16 output channels.
5. Input Signal Types: The module supports digital, analog, and thermocouple input signals.
6. Input Voltage Range: The analog input voltage range is +/-10V DC, while the thermocouple input range is -100°C to +2000°C.
7. Input Resolution: The analog input resolution is 12 bits.
8. Output Signal Types: The module supports digital and analog output signals.
9. Output Voltage Range: The analog output voltage range is 0-10V DC.
10. Output Resolution: The analog output resolution is 12 bits.
11. Communication: The module communicates with the control system through a serial communication interface.
12. Mounting: The module can be mounted on a DIN rail.
13. Operating Temperature: The module is designed to operate within a temperature range of 0°C to 60°C.
14. Storage Temperature: The module can be stored within a temperature range of -40°C to 85°C.
15. Humidity: The module can operate within a relative humidity range of 5% to 95% non-condensing.
16. Dimensions: The module measures 7.3 x 9.7 x 1.5 inches (185 x 246 x 38 mm) and weighs 2.7 pounds (1.2 kg).

Overall, the GE DS200DSFBG1ACB I/O module is an important component of industrial control systems that provides interface signals to and from field devices, and supports a range of features to help improve system flexibility and performance.

Product picture display
