GE DS3800NLCB I/O Module

GE DS3800NLCB I/O Module

Technical data of product parameters

The GE DS3800NLCB is an I/O (input/output) module used in industrial control systems. This module is responsible for receiving inputs from sensors and other devices and sending output signals to actuators and other control elements. Here are some details about the DS3800NLCB module:

1. Functionality: The DS3800NLCB module is an I/O module that provides a range of digital and analog inputs and outputs for use in industrial control systems.
2. Compatibility: The DS3800NLCB module is compatible with a range of industrial control systems, including those that use the GE Mark V control platform.
3. Input Channels: The module has 16 digital input channels and 2 analog input channels.
4. Output Channels: The module has 16 digital output channels and 2 analog output channels.
5. Input Voltage Range: The analog input channels accept input voltages in the range of 0 to 10V DC.
6. Output Voltage Range: The analog output channels provide output voltages in the range of 0 to 10V DC.
7. Diagnostic Features: The module includes built-in diagnostic features, such as self-tests and fault detection capabilities, to help identify and troubleshoot issues in the industrial control system.
8. Operating Temperature Range: The module can operate in a temperature range of 0 to 60 degrees Celsius.
9. Dimensions: The module has dimensions of 30.5 x 24.1 x 20.3 cm.
10. Weight: The module weighs approximately 2.3 kg.

The DS3800NLCB module is an essential component of an industrial control system, as it provides the necessary I/O capabilities to receive input signals from sensors and send output signals to control elements. Its compatibility with a range of control systems, built-in diagnostic features, and digital and analog I/O capabilities make it an ideal choice for use in various industrial applications.

Product picture display
