Technical data of product parameters

The GE DS3800NPDA is a spare parts module used in industrial control systems. This module is used to replace faulty or damaged parts in existing systems to ensure smooth and uninterrupted operation. Here are some details about the DS3800NPDA module:

1. Functionality: The DS3800NPDA module is a power supply module that provides DC power to other components in the control system. It converts incoming AC power to regulated DC power that is suitable for use in the system.
2. Compatibility: The DS3800NPDA module is compatible with a range of industrial control systems, including those that use the GE Mark V control platform.
3. Input Voltage: The module operates on an input voltage of 120V AC, 50/60Hz.
4. Output Voltage: The module provides a regulated output voltage of 24V DC, which is used to power other components in the system.
5. Output Current: The module has a maximum output current of 40A, which is sufficient to power multiple components in the system.
6. Redundant Design: The DS3800NPDA has a redundant design, which means that it includes two power supplies that operate in parallel. This ensures that the system remains operational even if one of the power supplies fails.
7. Diagnostic Features: The module includes built-in diagnostic features, such as self-tests and fault detection capabilities, to help identify and troubleshoot issues in the industrial control system.
8. Operating Temperature Range: The module can operate in a temperature range of 0 to 50 degrees Celsius.
9. Dimensions: The module has dimensions of 20.3 x 15.2 x 35.6 cm.
10. Weight: The module weighs approximately 4.5 kg.

The DS3800NPDA module is an essential component of an industrial control system, as it provides the regulated DC power needed to operate other components in the system. Its redundant design, diagnostic features, and compatibility with a range of control systems make it an ideal choice for use in various industrial applications.

Product picture display
