GE DS3800NSFC Gas Turbine Module

GE DS3800NSFC Gas Turbine Module

Technical data of product parameters

The GE DS3800NSFC is a gas turbine control module designed for use in power generation and other industrial applications. Here is a detailed introduction to this module:

1. Functionality: The DS3800NSFC is a control module that provides advanced control and monitoring capabilities for gas turbine systems. It interfaces with other control modules and sensors to help ensure safe and efficient operation of the gas turbine.
2. Inputs: The module accepts inputs from various sensors and switches located throughout the gas turbine system. These inputs include temperature, pressure, and speed signals.
3. Outputs: The module provides outputs to various devices throughout the gas turbine system, including control valves and actuators. These outputs help to regulate the operation of the gas turbine and ensure safe and efficient performance.
4. Communication protocol: The module uses the GE Field Control Communication protocol to communicate with other control modules and devices in the gas turbine system.
5. Compatibility: The module is compatible with a range of GE gas turbine systems, including the Frame 5, Frame 6, and Frame 9 series.
6. Diagnostic features: The module includes built-in diagnostic features, such as self-tests and fault detection capabilities, to help identify and troubleshoot issues in the gas turbine system.
7. Operating temperature range: The module can operate in a temperature range of -40 to 70 degrees Celsius.
8. Power supply: The module requires a power supply of 5V DC, +/- 5%.
9. Dimensions: The module has dimensions of 3.25 x 12.25 x 21.75 cm.
10. Weight: The module weighs approximately 0.18 kg.

Overall, the GE DS3800NSFC is a highly advanced and sophisticated control module designed to help ensure safe and efficient operation of gas turbine systems. With its advanced monitoring and diagnostic capabilities, it is an essential component of any modern gas turbine control system.

Product picture display
