GE DS3800NVCB Gas Turbine Card

GE DS3800NVCB Gas Turbine Card

Technical data of product parameters

The GE DS3800NVCB is a gas turbine card used in the control system of GE heavy-duty gas turbines. It is responsible for monitoring and controlling various aspects of the turbine’s operation, including fuel flow, combustion temperature, and exhaust emissions. The card is part of GE’s Mark V control system, which is used in many different gas turbine models.

The DS3800NVCB card is a versatile module that can be used in a variety of applications. It is equipped with eight analog input channels and four analog output channels, as well as eight digital inputs and eight digital outputs. The analog input channels can measure a wide range of signals, including temperature, pressure, and flow rate. The analog output channels can provide control signals to regulate fuel flow, air flow, and other parameters.

The card is also equipped with a microprocessor that runs specialized software to control the gas turbine’s operation. The software can be customized to suit the specific needs of each gas turbine installation. In addition, the card has a built-in memory that can store important data, such as operating parameters, fault codes, and performance data.

The GE DS3800NVCB card is designed to be robust and reliable, even in harsh environments. It can operate in temperatures ranging from -40°C to +70°C (-40°F to +158°F), and can withstand high levels of shock and vibration. The card is also equipped with various protection features, such as overvoltage and overcurrent protection, to ensure safe and reliable operation.

Overall, the GE DS3800NVCB card is an essential component of the control system for GE gas turbines. It provides precise and reliable monitoring and control of critical turbine parameters, helping to ensure safe and efficient operation.

Product picture display
