GE DS3828CSN06A Starter Module

GE DS3828CSN06A Starter Module

Technical data of product parameters

The GE DS3828CSN06A Starter Module is a high-performance control module designed for motor starting applications. It is used in conjunction with a contactor to control the motor’s start and stop operations. The module provides advanced features such as motor overload protection, phase loss detection, and phase reversal protection.

The GE DS3828CSN06A Starter Module is compact in size and easy to install, making it an ideal solution for a wide range of industrial applications. It is compatible with various types of motors, including induction, synchronous, and DC motors. The module can operate at a wide range of temperatures and has a long service life.

Some of the key features of the GE DS3828CSN06A Starter Module include:

• Power supply: 24 VDC nominal, ±10%
• Power consumption: 4 watts maximum
• Operating temperature: -20°C to +60°C (-4°F to +140°F)
• Storage temperature: -40°C to +85°C (-40°F to +185°F)
• Humidity range: 5% to 95% (non-condensing)
• Motor overload protection: adjustable trip level and time delay
• Phase loss detection: detects loss of any phase in three-phase supply
• Phase reversal protection: prevents motor from running in the wrong direction
• Start and stop control inputs: 24 VDC signal or dry contact closure
• LED indicators: provide status information on power, input signals, and output signals
• Dimensions: 85 mm x 145 mm x 67 mm (3.35 in x 5.71 in x 2.64 in)
• Weight: 0.5 kg (1.1 lbs)

Overall, the GE DS3828CSN06A Starter Module is a reliable and high-performance control module that can improve the efficiency and reliability of motor starting operations. Its advanced features and compact size make it an ideal solution for a wide range of industrial applications.

Product picture display
