GE gas turbine card IS200VAICH1D power module GE

GE gas turbine card IS200VAICH1D power module GE

Technical data of product parameters

The VMIVME-3122 Board can be programmed to scan the input channels
continuously, to read input channels individually, or to acquire data in timed orIS200VAICH1D
synchronized bursts.
Table 3-8 on page 54 ‘Scan Mode Configuration’ summarizes the various operating
modes, all of which are described in this section. The default settings assume a 64
channel option. If a 32- or 16-channel option is used, substituteIS200VAICH1D
channels is mentioned.
Auto Scanning
This default operating mode is selected by a reset operation, or by clearing both IS200VAICH1D
mode control bits. All active channels are scanned continuously in this mode, and
any channel can be read at any time without affecting the scanning operation.
To set the board for Auto Scanning, either do a reset operation IS200VAICH1D The indicatedIS200VAICH1D code also establishes the following
conditions:
• 64-word buffer
• 64-channel block size
• Interrupt on data ready flag if interrupt is enabled
• Fixed gain x1
Single Scan
The Single Scan operating mode samples all the active channels one time and stops.
The scan sequence will not start again until the selected trigger mode is initiated. The
Single Scan mode can be triggered by a software command, external trigger, or by the
interval timer. The steps to program single scan in each of these cases is described
below.
Single Scan Software Triggered
Write $8000 to CSR (relative address $0002). This enables the software trigger. The
indicated CSR code also establishes the following conditions

Product picture display

I guess you want to know

What if there is a quality problem?

Seven-day acceptance period, one-year warranty period

When can we deliver it?1-3 working days

How about the quality?New or second-hand

How to get the quotation?Phone, WeChat, email and whatApp can all be used
