GE IC660BBA020 system module spare parts

GE IC660BBA020 system module spare parts

Technical data of product parameters

The Main Processor log is available via the main processor front panel serial port using a TC304-01 maintenance cable. (The same information is available via Ethernet, however IC660BBA020
diagnostics must be activated first. This can be done by entering tcp_diag=1 into the Additional
text box on communication interface module parameters dialog box in the system configuration
editor.Connect the maintenance cable to a PC serial port and to the main processor front panel socket. IC660BBA020
Set the keyswitch on the main processor to the Run position.
Open a terminal program such as Hyperterminal (supplied with Windows) or Tera Term. Choose
the appropriate PC com port and select 19.2kbps. Press Enter in the communications window.
The following prompt should appear.Carefully insert the standby module into the slot allocated in the system configuration.
Press the two ejector levers flush with the module faceplate.
2) The replacement module will go into standby mode. Check that all its Healthy LEDs are
green and its Standby LED is steady green, as shown in Figure 15-13. This may take a IC660BBA020
few seconds.
3) Use the release key (but do not rotate the top and bottom levers open) on the
primary/active module. The replacement module should now become active, indicated by
its Active LED being steady green. The primary module should now revert to standby
mode, indicated by its Standby LED being steady green, as shown in Figure 15-14. (Note:
If the primary module has an actual fault, the swap will be automatic and the levers will
not have to be operated to initiate the change-over.)
4) Wait several minutes to observe that the replacement module stays healthy. Also make
sure that all the TxRx LEDs on the corresponding expander processor modules continue
to blink with an orange color. (There are two LEDs on the expander processor, one green
and one red. If the three slices have two way communications, the LED color will be
orange.)
5) Rotate the levers fully open and pull out the faulty modul

Product picture display
