TheIS210DTAOH1AA system provides a range of termination assemblies to connect
field wiring to the I/O modules. A termination assembly is a printed circuit
equipped with screw terminal blocks for the field wiring (and in some cases
fuses) and connectors for the plug-in I/O modules. Termination assemblies
give the system designer flexibility when configuring redundant and fault
tolerant systems.
Termination assemblies come in three types: simplex, dual or triple to
accommodate one two or three I/O modules. Each termination assembly
provides connections for up to IS210DTAOH1AA 16 channels but can accommodate 8 or 16
channel modules.
The version illustrated is a simplex termination assembly for a digital input
module. The field wiring connectors are located to the left, the fuses have a
cover (shown open) and the module sockets are to the right. Each fuse cover
has a label that identifies the fuse numbers.The T9892 Terminal Assembly module operates in conjunction with the T9451
Digital Output Module and provides 8 dual configuration output channels. It
shares the same pin-out as the standard AADvance T9852 Digital Output
Terminal Assembly and has the same coding peg configuration. The difference IS210DTAOH1AA
is that the T9892 has a separate connector for the field power input voltage
connections (the left most terminal block shown below). It also has additional
fusing to give extra protection against field faults.Field device wiring connections are made to industry-standard screw terminal
blocks on the termination assemblies. Terminals are easy to access without
needing to dismantle assemblies. The specification for the field wiring sizes is
given in the topic “Power and External Connector Wiring Requirements”.
This illustration shows field wiring connections at the termination assemblies.A typical controller arrangement is shown with processor modules installed on
the processor base unit and an I/O base unit mated with the processor base
unit. I/O modules are installed on the base unit and a termination assembly
plugged into the I/O base unit.The depth of the base unit (18 mm) excludes the parts of the backplane IS210DTAOH1AA
connectors that mate inside the module connectors. Adding the depth of a
module (118 mm) to the depth of the base unit gives the overall depth of the
controller assembly at 136 mm.
