GE module IC697PCM711 system card

GE module IC697PCM711 system card

Technical data of product parameters

IC697PCM711 the rung goes from false-to-true, the control element Enable (EN) bit is
set. When the instruction is placed in the ASCII queue, the Queue bit (EU) is
set. The Running bit (IN) is set when the instruction is executing. The DN bit
is set upon completion of the instruction.
Once either the end of line character(s) are received or, the requested number
of characters are in the buffer, all characters (including the end-of-line
characters) are moved to the destination string. The number of characters
moved is stored in the POS word of the control block. The number in the
Characters Read field is continuously updated and the Done bit (DN) is not
set until either the end of line character(s) are received or, all of the characters IC697PCM711
have been read.The occurrence of recoverable or non-recoverable user faults causes the
processor to read S:29 and execute the subroutine number contained in S:29.
If the fault is recoverable, the routine can be used to correct the problem and
clear the fault bit S:1/13. The processor then continues in the REM Run
mode. IC697PCM711
The routine does not execute for non-user faults.
Words S:20 and S:21 can be examined in your fault routine to pinpoint the file IC697PCM711
and rung number where the fault occurred. If the fault occurred outside of the
ladder scan, this value will contain the rung number where the TND, END, or
REF instruction is located. Use words S:20 and S:21 with your power-up
protection fault routine to determine the exact point that the previous power
down occurredA possible method of accomplishing this is shown in the following examples.
The user fault routine is designated as file 3.
When a recoverable or non-recoverable user error occurs, the processor scans
subroutine file 3. The processor jumps to file 4 if the error code is 0020 and it
jumps to file 5 if the error code is 0034h. For all other recoverable and
non-recoverable errors, the processor exits the fault routine and halts
operation in the fault mode.

Product picture display
