GE PCH1026 module off the shelf

GE PCH1026 module off the shelf

Technical data of product parameters

Each baseplate in a Series 90-30 system is identified with a unique number called a “Rack
Number.” Rack Numbers for Expansion and Remote baseplates are selected by setting a DIP
switch located on each baseplate directly above the connector for Slot 1. Rack number 0 must PCH1026
always be present and is assigned, by default, to the CPU rack (the CPU baseplate does not have
this DIP switch). Racks do not need to be contiguously numbered, although for consistency and
clarity, it is recommended that rack numbers not be skipped (use 1, 2, 3 – not 1, 3, 5). Rack
numbers must not be duplicated within a system. The following table shows the DIP switch PCH1026
positions for rack number selection.
IC693ACC308 Front Mount Adapter Bracket. Used to mount a baseplate to the front
face of a 19” rack. Install the adapter bracket by inserting the tabs at the top and bottom of
the adapter bracket into the corresponding slots at the top and bottom of the plastic
baseplate cover. NOTE: Although the figure below shows the plastic baseplate cover
removed, this is for illustration purposes only. It is not necessary to remove the cover PCH1026
to install the bracket. With the bracket in place, insert and tighten the two screws (included
with the bracket) through the back of the baseplate holes into the threaded holes in the bracket.

IC693ACC313 Recessed Mount Adapter Bracket. Used to recess mount a baseplate
inside a 19” rack. A baseplate mounts on the rear panel of this adapter bracket using four
8-32 (4 mm) screws, nuts, lockwashers and flat washers. The Adapter Bracket bolts
through its four slotted holes to the face of the 19” rack using applicable hardware
(lockwashers recommended)
