HONEYWELL 51305896-200 NIM MODEM Adjusting Board
Technical data of product parameters
The Honeywell 51305896-200 NIM Modem Adjusting Board is a component used in the Honeywell TDC 3000 Distributed Control System (DCS). The NIM (Network Interface Module) Modem Adjusting Board is designed to be used in conjunction with the NIM module, which provides communication between the DCS and field devices, such as sensors and actuators.
The 51305896-200 board is responsible for adjusting the modem settings on the NIM module to ensure proper communication between the DCS and field devices. It features several adjustable potentiometers that can be used to adjust the modem’s baud rate, line impedance, and other communication parameters.
The board is designed to be easy to install and use, with a simple interface and clearly labeled controls. It is typically used by trained technicians or engineers who have experience working with the TDC 3000 DCS and its associated components.
Overall, the Honeywell 51305896-200 NIM Modem Adjusting Board is an important component of the TDC 3000 DCS, providing critical communication capabilities that are essential for industrial processes in a wide range of industries.
Product picture display
