HONEYWELL CC-PDIL01 51308388-175 counting board
Technical data of product parameters
When two dissimilar metals (a thermocouple) are joined together, a voltage (the CC-PDIL01 51308388-175
Seebeck Voltage) is generated between them. This voltage is directly related to the
temperature at the junction of the two metals. The relationship between the voltage
and the temperature can be best described by a fifth order polynomial, determined
by the two types of metals that are joined.
To measure the voltage (Vt) between the two metals, a voltmeter (in this case, an
analog input card) must be connected to each wire (see Figure 4-5). Unfortunately,
this produces two new junctions and voltages (V1 and V2) between the terminals CC-PDIL01 51308388-175
and the thermocouples. The following formula is used to find Vt: Vt = Vm -V1 -V2.
It is not possible to measure V1 and V2 without inducing more junctions and
voltages; therefore, the analog input subsystem has a temperature sensor on the
Personality module (1C31116G04) to measure the temperature (Tj) at the terminal
block of the base unit.
A conversion formula, determined from the junction metal and thermocouple
metals, is used to calculate the combined voltage of V1 and V2. This is called Cold CC-PDIL01 51308388-175
Junction Compensation.Personality module of the analog input subsystem includes a temperature sensor IC.
This is used for measuring the temperature of the terminal block to provide cold
junction compensation for thermocouple inputs.
This module is used in conjunction with a terminal block cover (1C31207H01) to
maintain a uniform temperature of the terminal block and sensor area. The cover fits
over an entire base; however, the sensor will only accurately measure the
temperature under the half of the cover where the temperature sensor personality
module is installed. Therefore, if both modules under the cover require cold
junction compensation, they will each require the temperature sensor personality
module
