Honeywell CC-PDOB01 51405043-175 analog output module

Honeywell CC-PDOB01 51405043-175 analog output module

Technical data of product parameters

ThisCC-PDOB01 51405043-175 is a basic check of program and data memory, along with the
microcontroller’s data, address, and control buses. A “0” indicates that
there is no error condition. A “1” indicates an unrecoverable error condition in the field.
Bit 14: This bit indicates the fault status of the digital temperature sensor. A “0” CC-PDOB01 51405043-175
indicates the sensor is present and communicating properly with the microcontroller. A “1” indicates a fault exists; either there is no sensor
present, or problems exist in communicating with the sensor. On an uncalibrated module, a sensor failure is always reported because the uncalibrated status prevents the sensor from being checked.
Bit 15: This bit indicates the point fault status of the module. It is the logical
“OR” of the eight individual point quality statuses plus bits 1, 7, 12, and
13 of this register. A “0” indicates that all eight points have good quality
and no module errors exist. A “1” indicates that at least one of the points
has bad quality and is therefore in fault.
A subsequent read of the Point Quality Status Register at Address 12 (C in Hex) will
reveal which of the eight points has bad quality and the cause of the bad quality CC-PDOB01 51405043-175
condition (refer to Table 4-6). The Address 12 (C in Hex) Point Quality Status
Register contains data only when the module fault is due to a bad point quality; that
is, bits 7, 12, and 13 of this register or the forced error bit are not set. Note that the
Temperature Sensor (Address 8) status is treated separately and is not included in CC-PDOB01 51405043-175
this module point fault bit.Word address 14 (E in Hex) serves the purpose of the Current/Voltage
Configuration/Status Register. The bit definitions for this register are encoded as
shown in Table 4-5.
The default state of the register under normal operation is “0” for voltage inputs.
The lower 8 bits are configuration bits which are written to and read from the
module. The upper 8 bits are read-only status bits indicating the blown fuse status
only for those channels which have been configured as current inputs

Product picture display
