Honeywell FCTSAI1620M module
Technical data of product parameters
The Honeywell FCTSAI1620M is a single-channel analog input module that is designed for use with Honeywell’s ControlEdge HC900 process controller. The module is compact in size, occupying just one slot in the HC900’s backplane, and provides high-performance analog input capabilities.
The FCTSAI1620M module is a universal analog input module, which means that it can accept a wide range of input types, including voltage, current, RTD, and thermocouple inputs. The input range is programmable for each input type, which makes the module highly flexible and adaptable to different process control requirements.
The module provides high resolution and accuracy, with 16-bit resolution and ±0.1% of full scale accuracy for voltage and current inputs, and ±0.2% of full scale accuracy for RTD and thermocouple inputs. This makes it suitable for precise measurements and ensures that control systems receive accurate input signals.
The FCTSAI1620M module also features fast response times, with a response time of less than 100ms. This means that control systems can receive input signals rapidly, enabling fast and effective control of the process being monitored.
The module provides input isolation, with 1500Vrms isolation between the input and backplane. This ensures that the control system is protected from potentially damaging input signals.
The FCTSAI1620M module is designed for easy installation and configuration. It is hot-swappable, which means that it can be replaced without disrupting the operation of the HC900 process controller. The module is also compatible with Honeywell’s Universal Connection System (UCS), which provides a simple and standardized wiring interface for easy installation.
Overall, the Honeywell FCTSAI1620M module provides high-performance analog input capabilities, with flexibility, accuracy, and fast response times. Its universal input type and programmable input range make it suitable for a wide range of process control applications, and its input isolation and easy installation make it a reliable and convenient choice for industrial process control.
Product picture display
