Industrial control card 64SD1-08KRF1-13 in stock

Industrial control card 64SD1-08KRF1-13 in stock

Technical data of product parameters

A single, regulated +5V supply (current limited to approximately 150 mA) is available through
the I/O connectors on the front of the module. This supply is generated on the module and is 64SD1-08KRF1-13
isolated from the backplane. Its power input comes from the +5V logic supply on the PLC
backplane. By installing jumpers on the appropriate pins on the I/O connector, you can choose
to power the inputs from this internal supply instead of powering them with an external user
provided supply. If this internal supply is used to power the inputs, additional loading will be 64SD1-08KRF1-13
placed on the PLC’s +5V power supply. Backplane isolation between the field side and logic
side is provided by opto-couplers on the module. There are no special fault or alarm
diagnostics reported. LED indicators (labeled A1 – A8, B1 – B8, C1 – C8, D1 – D8) at the top
of the module provide the ON/OFF status of each input point.
This module is configured as a 32-point input type and uses 32 bits of discrete %I input data.
Current into an input point results in a logic 1 in the input status table. This module can be 64SD1-08KRF1-13
installed in any I/O slot of a 5 or 10-slot baseplate in a Series 90-30 PLC system.
Connections to the input circuits are made from the user’s input devices to two male (pin-type)
24-pin connectors (Fujitsu FCN-365P024-AU) mounted on the front of the module. The
connector mounted on the right of the module (front view) interfaces with groups A and B. The
connector on the left side of the module interfaces with groups C and D.
Wiring from the module’s connectors to field devices is made through a cable having a mating
female connector on one end and stripped and tinned wires on the other end. You can purchase
a pair of pre-wired cables, catalog numbers IC693CBL327 and IC693CBL328 or, if required
for your application, build your own cable. Refer to “Building Cables for 24-Pin Connectors”
in the IC693CBL327/328 data sheet in Appendix C of this manual for more information.
