LC100SSP7 system card module

LC100SSP7 system card module

Technical data of product parameters

For most LC100SSP7 applications, normal convection cooling will keep the SLC 500
controller components within the specified operating range of 0 °C…60 °C
(32 °F…140 °F). Proper spacing of components within the enclosure is usually
sufficient for heat dissipation.
In some applications, a substantial amount of heat is produced by other
equipment inside or outside the enclosure. In this case, place blower fans
inside the enclosure to assist in air circulation and to reduce hot spots near the
SLC 500 controller.
Additional cooling provisions might be necessary when high ambient
temperatures are encountered.The grounding-electrode system is at earth-ground potential and is the central
ground for all electrical equipment and ac power within any facility. Use a
grounding-electrode conductor to connect the ground bus to the
grounding-electrode system. Use at minimum 8.3 mm2
(#8 AWG) copper wire LC100SSP7
for the grounding-electrode conductor to guard against EMI. The National
Electrical Code specifies safety requirements for the grounding-electrode
conductor.
Europe: Reference EN 60204 for safety information on grounding. Also, refer
to Allen-Bradley Programmable Controller Grounding and Wiring Guidelines, publication 1770-4.1, and System Design for Control of Electrical Noise,
publication GMC-RM001.
United States: An authoritative source on grounding requirements for most
installations is the National Electrical Code. Also, refer to Allen-Bradley
Programmable Controller Grounding and Wiring Guidelines, publication
1770-4.1 and System Design for Control of Electrical Noise, publication
GMC-RM001. LC100SSP7
In addition to the grounding required for the SLC 500 controller and its
enclosure, you must also provide proper grounding for all controlled devices in
your application. Care must be taken to provide each device with an acceptable
grounding path.
This figure shows you how to run ground connections from the chassis to the
ground bus. The recommended grounding method is shown below. Using a
ground bus reduces the electrical resistance at the connection.

Product picture display
