NI PXI-5114 Industrial Control Card Module

NI  PXI-5114 Industrial Control Card Module

Product Details Introduction

NI PXI-5114 is a high-performance industrial control card module launched by National Instruments (NI). The following are some of the main product features of this module:
High speed data acquisition: The PXI-5114 module has high-speed data acquisition capabilities, enabling fast and accurate signal acquisition. It supports high-speed analog-to-digital conversion (ADC) and can collect analog signals at high sampling rates.
High resolution: This module has a high-resolution ADC, which can achieve accurate signal measurement and acquisition. High resolution enables the module to capture and analyze small signals, making it suitable for applications that require high precision.
Multi channel input: The PXI-5114 module supports multi-channel analog inputs, with each channel having independent input capabilities. It can simultaneously collect signals from multiple channels and is suitable for multi-channel data acquisition and analysis applications.
Wide input range: This module has a wide input range and can adapt to the input requirements of different signal sources. Users can configure the input range and gain as needed to adapt to different measurement scenarios and signal amplitudes.
Flexible clock and trigger functions: The PXI-5114 module is equipped with flexible clock and trigger functions, which can achieve precise data collection and synchronization operations. It supports multiple triggering modes and sources, including software triggering, external triggering, and digital input triggering, to meet the needs of different applications.
Powerful software support: This module is equipped with NI-DAQmx driver software and development tools for NI software platforms such as LabVIEW, providing rich functionality and easy-to-use programming interfaces. Users can use these tools to develop, debug, and execute data collection programs, achieving flexible and customized control applications.

Product picture display
