NI PXI-5421 Generator Module
Product Details Introduction
NI PXI-5421 is a generator module from National Instruments (NI) used for the PXI (PCI eXtensions for Instrumentation) bus architecture. This module has a wide range of applications, providing high-performance and flexible signal generation functions. The following are the main product features of this module:
High precision signal generation: The PXI-5421 module has high-precision signal generation capability, which can generate accurate analog and digital signals. It adopts high-quality DAC (digital to analog converter) and clock source, providing stable and accurate signal generation.
Wide frequency range: This module supports a wide frequency range and can generate signals from DC to high-frequency. It is suitable for various applications, including frequency response testing, signal modulation, oscillator calibration, etc.
High resolution and high sampling rate: The PXI-5421 module has high resolution and high sampling rate, enabling precise signal control and reproduction. It supports high-speed data conversion and output, suitable for high demand signal generation applications.
Multichannel generation: This module supports multi-channel signal generation and can generate multiple independent signal channels simultaneously. Each channel has an independent generation circuit and parameter configuration, allowing for independent signal generation operations.
Multiple signal waveforms: The PXI-5421 module supports various common signal waveforms, such as sine wave, square wave, triangular wave, pulse wave, etc. It also supports user-defined waveforms, which can flexibly meet the needs of different applications.
Pulse generation: This module supports the generation of pulse signals, including single pulses, repetitive pulses, and pulse sequences. It has flexible pulse parameter configuration and can generate various pulse signals for testing and debugging.
Flexible triggering and synchronization functions: The PXI-5421 module has flexible triggering and synchronization functions, which can be configured according to user needs. It supports multiple triggering sources and modes to achieve precise signal synchronization and collaborative work.
High speed data transmission and processing: This module supports high-speed data transmission and processing, and can achieve efficient data exchange with other PXI modules and devices. It is also integrated with NI’s software platform, providing comprehensive testing, measurement, and automation functions.
Product picture display
