NI PXI-6722 Analog Output Module

NI  PXI-6722 Analog Output Module

Product Details Introduction

NI PXI-6722 is an analog output module of National Instruments (NI), which has high-precision and high-speed analog signal generation function. The following are the product features of this module:
High precision analog output: The PXI-6722 module provides multiple analog output channels, which can generate high-precision analog signals. It supports different output ranges and resolution options to meet the needs of different applications. The high-precision output capability of this module ensures the accuracy and stability of the generated analog signal.
High speed update rate: This module has a high speed update rate and can achieve fast analog signal generation. It supports multiple update modes and sampling rate options, which can meet the needs of applications that require high-frequency signal generation. The high-speed update rate enables analog signals to respond in real-time to system requirements.
Multiple output waveform types: The PXI-6722 module supports multiple output waveform types, including continuous waveform, finite point waveform, segmented waveform, etc. Users can generate various complex analog signals through software configuration to meet the requirements of different applications.
High resolution and low noise: This module uses a high-resolution analog converter (DAC) to achieve accurate signal generation. It also has a low noise design that can reduce the impact of external interference on the output signal quality and provide high-quality analog signals.
Flexible triggering and synchronization functions: The PXI-6722 module supports multiple triggering and synchronization options, enabling precise time synchronization and trigger control with other modules and devices. This is very important for applications that require multi-channel synchronous output or synchronization with external events.
Software support and development environment: This module is equipped with NI-DAQmx driver and LabVIEW software tools, providing rich functionality and an easy-to-use development environment. Users can easily configure, control, and analyze the output signals of the module, simplifying the development and debugging process.
PXI standard compatibility: The PXI-6722 module adopts a standard PXI bus architecture and can be extended and integrated with other PXI modules and devices. Users can build customized analog output systems based on application requirements.

Product picture display
