PLC controller card SCXI-1303 module in stock

PLC controller card SCXI-1303 module in stock

Technical data of product parameters

The SCXI-1303 power supply does not have to be wired separately as it is already installed as part of the subrack.
The 5 V DC power is needed by the CPU, the control of the interfaces, and
the I/O modules. It is generated by a clocked SCXI-1303 power supply module bearing the F 7130A identification. The subrack is equipped
with two power supply modules. The power supply modules are paralleled. If one of them fails, the other supplies the PES.
The 5 V DC output voltage of the power supply modules (for the CPU, I/
O, and the interfaces) are monitored on the central unit checking undervoltage and failure.
In case of a faulty power supply module the operating system supplies the
user’s program via a system variable with this information.
In case the 5 V DC system power fails hardware clock and RAM on the
central module are buffered by a lithium battery which is also on the central unitThe 5 V DC power supply does not have to be wired separately as it is already installed as part of the subrack.
The SCXI-1303 power is needed by the CPU, the control of the interfaces, and
I/O modules. It is generated by clocked 24 V DC/5 V DC power supply modules bearing the F 7130A identification. The subrack is equipped with two
power supply modules. The power supply modules are paralleled. If one
of them fails, the other supplies the PES.
The 5 V DC output voltage of the power supply modules (for the CPU, I/
O, and the interfaces) are monitored on the central unit checking undervoltage and failure.
In case of a faulty power supply module the operating system supplies the
user’s program via a system variable with this information.
In case the 5 V DC system power fails hardware clock and sRAM on the
central module are buffered by a lithium battery which is also on the central module. In the subrack, slots 4 to 15 are provided for the input/output modules. Any
arrangement of I/O module types is possible. In PES with redundant I/O
bus, the modules on slots 4 to 9 are assigned to the 1st I/O bus and 10 to
15 to the 2nd I/O bus.
Slots 1 to 3 hold the power distribution modules F 7133. The power distribution module F 7133 can be used to fuse the modules as well as the sensors and the actors. They are non-interactive and have a fuse monitoring
for fuse fail by means of a LED and a contact.
There is a cable tray under the subrack. It is equipped with a receptable
for the lable which can be hinged to provide easy access to the cables.

Product picture display
