PROSOFT PTQ-PDPMV1 power module

PROSOFT PTQ-PDPMV1 power module

Technical data of product parameters

The PROSOFT PTQ-PDPMV1 is a power module designed for use with the PROSOFT PROFIBUS DPV1 Master module. The PTQ-PDPMV1 provides reliable and consistent power to the master module, ensuring that it operates efficiently and effectively. Here’s a detailed introduction to this power module:

1. Power Input:

• Voltage range: 24VDC
• Maximum current: 0.25A
• Power consumption: 6W maximum

2. Power Output:

• Voltage range: 5VDC
• Maximum current: 1A
• Ripple voltage: less than 50mV peak-to-peak

3. Environmental:

• Operating temperature range: -40°C to 70°C
• Storage temperature range: -40°C to 85°C
• Humidity range: 5% to 95% non-condensing
• Vibration resistance: 2G @ 10-200Hz

4. Physical Characteristics:

• Dimensions: 94 mm (H) x 40 mm (W) x 115 mm (D)
• Weight: 0.21 kg

The PROSOFT PTQ-PDPMV1 power module is a reliable and efficient power source for the PROFIBUS DPV1 Master module. It has a compact and durable design, making it suitable for use in industrial environments. The power output is stable and consistent, which helps to ensure that the master module operates effectively.

It’s important to note that the specifications for the PROSOFT PTQ-PDPMV1 power module may vary depending on the specific model and revision. It’s recommended to consult the product documentation or contact the manufacturer for detailed and up-to-date information on specifications, features, and performance characteristics.

Product picture display
