SCXI-1326 automation spare parts

SCXI-1326 automation spare parts

Technical data of product parameters

TheSCXI-1326 connection of the I/O level with the central device is established
via the I/O bus. The I/O bus coupling modules are already integrated in the
central rack. With the I/O rack the connection to the I/O bus is via a coupling module F 7553 installed in slot 17. The connection of the bus between the individual subracks is establiblished at the rear side via the
BV 7032 data cable.To terminate the I/O bus, an F 7546 module is plugged in at the beginning and the end.
The 5 V DC power supply does not have to be wired extra as it is already
part of the installation.
To supply the I/O racks the 5 V DC power supply with corresponding GND
is available at the rear side of the central rack.
The 5 V DC power needed for the microprocessor system and as control
current for theSCXI-1326modules is generated from the 24 V DC power of thesystem via clocked 24 V DC /5 V DC power supply modules bearing the
F 7126 identification. One central rack can be equipped with a maximum
of 3 power supply modules. The power supply modules are switched in
parallel. One or two power supply modules are usually able to supply the
PES. A further power supply module is used to increase availability.
The output voltage of the power supply modules is checked as to undervoltage and failure by a monitoring module F 7131.
In case of a faulty power supply module the operating system supplies the
user’s program via a system variable with this information.
In case the 5 V DC system power fails hardware clock and sRAM on the
central module are buffered by one lithium battery on the central module.
Two lithium batteries on the power supply monitoring module F 7131 are
to buffer the sRAM on the coprocessor moduleThe data connection of the I/O level with the central device is established SCXI-1326
via the I/O bus. The I/O bus coupling modules are already integrated in the
central rack. A data cable BV 7032 is used to connect the I/O bus between
central module 1 (XD.2) and central module 2 (XD.1).
With the I/O subrack the connection to the I/O bus is via a coupling module
F 7553 installed in slot 17. The connection of the bus between the individual subracks is established at the rear side via the BV 7032 data cable.
To terminate the bus, an F 7546 module is plugged in at the beginning and
the end.
The construction principle of the I/O bus is shown on the following page.
