Soft starter AB module 1761-L32AWA

Soft starter AB module 1761-L32AWA

Technical data of product parameters

The CI852, connects the FOUNDATION Fieldbus H1
(FF H1) to the AC 800M. The FF H1 has a 1761-L32AWA
communication speed of 31.25 kbit/s and is intended for
remote connection of field instruments. The CI852 is
connected to the bus via a transformer, and as such
neither supplies nor consumes bus electrical power.
The number of field instruments that can be connected
via the CI852 depends on the physical limitations of the FF H1 network, together 1761-L32AWA
with any software limitations (refer to the software documentation).
The FF H1 bus allows reuse of existing cabling for
4-20 mA analog signals. This means the cables often become the dominant
dimensioning factor. An FF configuration tool can be connected directly to the FF
H1 bus.
CI852 has been replaced by the CI860 communication interface (together with 1761-L32AWA
the LD800HSE linking device). CI852 is only described for legacy reasons.The CI854/CI854A/TP854 connects PROFIBUS DP to AC 800M. PRODFIBUS DP
slave devices like the remote I/Os S800 and S900 can be connected directly.
PROFIBUS PA slave devices can be connected via the PROFIBUS linking device
LD 800P.
The Baseplate TP854 has two female DB9 connectors for connecting
PROFIBUS DP with support of line redundancy. The baseplate has a code lock, see
Table 4 on page 75, that prevents the installation of an incorrect type of unit onto 1761-L32AWA
the TP854 Baseplate.The CI854/CI854A expansion unit contains the CEX-Bus logic, the CPU-kernel
with memory, the PROFIBUS interface with line redundancy unit and a DC/DC
converter that supplies the appropriate voltages from the +24V supply, via the CEXBus.

Product picture display
